LOW-EPOLYCARBONATE
Energy-Efficient Coatings That Transform Polycarbonate Sheets Into High-Performance Glazing
Finally, get the energy efficiency of low-E glass with the durability and weight savings of advanced polymers.
For decades, architects, engineers, and manufacturers have faced an impossible choice: energy-efficient glass that's heavy and fragile or lightweight polymers that lack thermal performance. NxLite has solved this problem with breakthrough, permanent coatings that deliver superior energy management on thermoplastic substrates, previously thought to be impossible.
Slash Energy Costs While Cutting Weight by Up to 50%
Traditional low-E glass offers excellent thermal performance but adds significant weight. NxLite's revolutionary coatings provide equal or superior energy performance on lightweight polycarbonate substrates, delivering the best of both worlds.
Thermal Performance Equal to Premium Low-E Glass
Same energy savings, half the weight
Weight Reduction
Dramatically enhances fuel economy/range, reduces shipping costs and easier installation
Factory-Applied Permanent Coating
Fused to the surface, guaranteed never to bubble, crack, or peel
Neutral Color & High Optical Clarity
Maintains aesthetic appeal while delivering performance
Impact Resistant
Withstands conditions that would shatter traditional glass
THE LINEUP: THREE COATINGS
NxLite low-E coatings on 3mm clear polycarbonate, monolithic/single pane center of glazing performance.
| On 3mm clear polycarbonate | Emissivity | U-factor | Tvis | Rf out | SHGC | Tsol |
|---|---|---|---|---|---|---|
| NxLite L80Clear and neutral aesthetic. | NxLite L80, Emissivity 0.081 | NxLite L80, U-factor 0.576 | NxLite L80, Tvis 81.7% | NxLite L80, Rf out 6.5% | NxLite L80, SHGC 0.613 | NxLite L80, Tsol 57.5% |
| NxLite S75Subtle neutral tint. | NxLite S75, Emissivity 0.058 | NxLite S75, U-factor 0.562 | NxLite S75, Tvis 74.3% | NxLite S75, Rf out 5.0% | NxLite S75, SHGC 0.483 | NxLite S75, Tsol 42.9% |
| NxLite S60*Mild grey/neutral tint. | NxLite S60*, Emissivity 0.030 | NxLite S60*, U-factor 0.545 | NxLite S60*, Tvis 59.7% | NxLite S60*, Rf out 15.4% | NxLite S60*, SHGC 0.321 | NxLite S60*, Tsol 26.6% |
Emissivity is how readily the surface radiates heat; lower keeps more heat on its own side. U-factor is the rate of heat loss in Btu/hr·ft²·°F; lower insulates better. Tvis is the share of visible light transmitted, Rf out the share reflected from the outside face, and Tsol the share of solar energy transmitted. SHGC is the fraction of solar heat that gets through, from 0 to 1. *Preliminary product performance values. Low-e coatings are not temperable and must be installed in no-touch positions such as IGUs or window inserts. Insulation and SHGC improve in insulated configurations.
INSULATED UNITS
NxLite L80 on polycarbonate in double- and triple-pane units, with a 90% argon fill.
| Polycarbonate units with NxLite L80 | VLT | Tsol | SHGC | U-factor | R-value |
|---|---|---|---|---|---|
| Double pane, 3mmL80 on surface 2, polycarbonate + polycarbonate. | Double pane, 3mm, VLT 70.9% | Double pane, 3mm, Tsol 51.6% | Double pane, 3mm, SHGC 0.554 | Double pane, 3mm, U-factor 0.257 | Double pane, 3mm, R-value 3.9 |
| Double pane, 6mmL80 on surface 2, polycarbonate + polycarbonate. | Double pane, 6mm, VLT 63.5% | Double pane, 6mm, Tsol 47.6% | Double pane, 6mm, SHGC 0.530 | Double pane, 6mm, U-factor 0.246 | Double pane, 6mm, R-value 4.1 |
| Triple pane, L80 on 2 + 43mm + 1.5mm + 3mm polycarbonate. | Triple pane, L80 on 2 + 4, VLT 57.5% | Triple pane, L80 on 2 + 4, Tsol 38.5% | Triple pane, L80 on 2 + 4, SHGC 0.451 | Triple pane, L80 on 2 + 4, U-factor 0.133 | Triple pane, L80 on 2 + 4, R-value 7.5 |
| Triple pane, L80 on 3 + 53mm + 1.5mm + 3mm polycarbonate. | Triple pane, L80 on 3 + 5, VLT 57.5% | Triple pane, L80 on 3 + 5, Tsol 38.5% | Triple pane, L80 on 3 + 5, SHGC 0.530 | Triple pane, L80 on 3 + 5, U-factor 0.132 | Triple pane, L80 on 3 + 5, R-value 7.6 |
VLT is the share of visible light transmitted. U-factor and R-value are measured with a 90% argon fill; R-value is the inverse of U-factor, so higher insulates better. These are headline figures: reflectance, UV transmission and air-filled U-factor are available on request.
WHY NXLITE VS. ALTERNATIVES
| NxLite™ Coated Polycarbonate | Clear Polycarbonate | Polycarbonate + Low-E Film | Low-E Glass | |
|---|---|---|---|---|
| Low-E thermal performance | Yes | No | Yes | Yes |
| Lightweight | Yes | Yes | Yes | No |
| Shatter-resistant | Yes | Yes | Yes | No |
| Permanent, factory-applied | Yes | No | No | Yes |
SHEET AVAILABILITY
Thicknesses
1.5, 2, 3, 4.5, 5.6 and 6mm. 3mm and 5.6mm are standard.
Sheet sizes
48 x 96, 60 x 96 and 72 x 96 in.
Minimum order
Minimum order quantities may apply.
Why Forward-Thinking Companies Partner With NxLite
Transform Your Industry Applications
Windows & Doors
Meet increasingly stringent energy requirements while reducing shipping costs and simplifying installation complexity.
Heavy Equipment & Agriculture
Glazing for tractors, excavators, and construction equipment that provides climate control, safety, and energy efficiency in the harshest environments.
Commercial Refrigeration
Enhanced thermal control reduces energy consumption while improving temperature stability, directly impacting your customers' bottom line.
Aviation & Mass Transit
High-performance glazing for aircraft, buses, and trains reduces fuel consumption while enhancing the passenger experience.
Storm Windows & Retrofit
Durable alternatives that deliver energy savings without the expense and disruption of complete window replacement.
Recreational Vehicles
Energy-efficient glazing that reduces HVAC load, extends battery life, and improves comfort for motorhomes and travel trailers.
Automotive Glazing
Lightweight glazing that maintains optical clarity and safety standards while reducing vehicle weight for better performance and range.
Ready to Revolutionize Your Energy Efficiency?
Discover how NxLite can elevate your polycarbonate glazing solutions and unlock the future of energy-efficient materials.
